SCADA system & HMI Programming

Objectives

• Understand how SCADA system work
• How to make GUI for SCADA system
• Make SCADA database
• Make system alarm data base
• Plot all variables and store the values
• Make security for the system
• Make the system animation with visual basic script
• Connect scada with any PLC
• Connect scada with internet
• Deal with HMI
• Remote control management
• Control from mobile

Course Outline

1-    Introduction

• What is scada system?
• Scada system content
• Difference between scada and DCS
• Indusoft web studio Overview
• Installation and register of the software

2-    Graphic Design editor

• Build a simple application
• Slider, bar graph, button, lamp
• Ribbon
• Quick Access Toolbar
• Project Explorer
• Database Spy
• Output Window

3-    Tags

• What is a Tag
• Internal Structure and Data Flow
• Boolean, Integer, Real, String
• Array, Class, Pointer
• Tag Properties

4-    Screen Groups

• Creating Screen Groups
  • Header
  • Navigation
  • Main
• Displaying Logo in Header

5-    Shapes and Formatting

• Shapes
• Formatting tools
  • Height and Width
  • X,Y Position
  • Layer
  • Alignment

6-    Active Objects

• Text
• Button
• Push Button
• Check Box
• Radio Button
• Combo Box
• List Box
• Smart Message
  • Message Display
  • Multistate Indicator
  • Multistate Pushbutton
• Text Box

7-    Animations

• Command
• Hyperlink
• Bargraph
• Text Data Link
• Color
• Position
• Resize
• Rotation
• Command Config
• Hyperlink Options
• Stacked Bargraph
• Text
• Color (By Limit, By Color)
• Position Reference
• Custom Rotation point
  • Rotating imported graphic

Grid Object

• Data Source
  • Class Tag
  • Text File
• Columns
• Conditional Filtering
• Inserting New information

9-    Trends

• Real-Time
• Historical
  • Trend Worksheet
• Numerical (X/Y plot)
• SPC (Statistical Process Control)

10-  Alarms

• Alarm/Event Control Object
• Alarm Worksheet
• Tag Properties
• History
  • File Location
  • File Format

11-  Symbols

• Linked Symbols
• Project vs. System Symbols
• Custom Properties/Categories
• Creating Your Own Symbols

12- Built-in Scripting

• Math and Logic Functions
• Interfaces
• Overview of Common Functions

13-  VBScript Interfaces

• Interfaces
• Sub and Functions
• Variables and Scope
• Additional Resources

14-   ActiveX and .NET Controls

• Active-X Slider and Web Browser
• .Net Progress Bar
• Interacting with the Controls

15-  Scheduler

• Event Types
  • Calendar
  • Clock
  • Change
• What Fields to Use
• Example Uses

16-    Tank Demo

• Adding Tags and Class
• Tank, Valves and Selection
• Simulation VBScript
• Contents of Tanks

 17-    Recipes

• Functions
  • Save
  • Load
  • Delete
  • Init
• VBScript to Select
• .XML

18-   Reports

• Worksheet
• Function
  • Disk
  • Prn
  • PDF
• Printing as TXT, RTF, HTML, CSV, and PDF

19-     Web Thin Client

• One of 3 Thin Clients
• Topology
• Publish Screens as HTML
• Configure Settings
• Configuring Microsoft IIS

20-    Secure Viewer

• One of 3 Thin Clients
• Installation
• Configuration using:
• Microsoft IIS
• Shared Folder
• Tag to Determine if Client or Server

21-     Mobile Access

• One of 3 Thin Clients
• 2 Parts
• Tabular
• MA (HTML5)
• Configuration
• Alarms, Process Tags, and Trends
• Webinar Video

22-     Events

• Event Settings
• Alarm/Event Control Object
• File Format
• Proprietary or Database Selection

23-    Access Database

• Default Database Configuration
• Creating an Access Database
• Configuring Alarm and Events
• Additional DB Interfaces

24-   SQL Database

• Default Database Configuration
• Creating an MS SQL Express Database
• Configuring the Grid Object
• Configure Connection
• Create VBScript with SQL Statements
• Using Output Window
• Database Worksheet

25-  Translation

• Development Environment
• Runtime
  • Translation Table
  • Set Language Function
• Web Thin Clients and Secure Viewer Can Use Different Languages

26-  Security

• Security Overview
• Configure Groups/Users
• Security with Objects
• Password Protecting Screens and Documents
• Security Webinar Video Online

27-   OPC

• What is OPC?
• What Technologies Does IWS Support?
• Optional
• OPC Foundation Member since 1998
• See OPC Webinar Online

28-    Remote Management

• Remote Agent
• Remote Management Connection
• Downloading to a Remote Runtime
• Remote DBSpy and Log win

29- Driver

• Driver Worksheets
  • Main Driver Sheet
  • Standard Driver Sheet(s)
  • Status
  • Manual
• Scan and Scaling
• Priority
• Troubleshooting
• Import Wizards
• Tag Integration

WORKSHOP STYLE

The workshop will be of five day’s duration consisting of interactive learning sessions, videos, examples and role-play exercises to provide the delegates with the knowledge and experience of using the key learning issues and techniques.
